Vibratory hammer PTC 120HD

Вибропогружатель
Фотография новости



The vibratory hammer PTC 120HD with constant eccentric moment technology is designed to work with large and heavy sheet piles and casings weighing up to 150 tons. This machine features a simple and reliable construction, which ensures smooth, long-term operation without significant maintenance costs. This model is well suited for performing work in open areas away from other objects.



Hydraulic power: 481 kW. Maximum frequency of vibrations: 23 Hz / 1380 rpm. Centrifugal force: 2555 kN, maximum extraction force: 1200 kN. The PTC 120HD vibratory hammer, in standard configuration, operates on slopes of up to 15 degrees. Upon individual request, it can be modified to work on slopes of up to 45 degrees. For working with sheet piles, the Agriplex 350 t clamping head is used, and for casings and columns, the Duplex 2×150 t clamping head is used.



The vibratory driving process is carried out with reduced noise levels. PTC 120HD vibratory hammers can be equipped with a cooling system for continuous operation.

Technical specifications

Eccentric moment
120 m.kg
Hydraulic power
481/654 kW/hp
Max. operating pressure
350 bar
Hydraulic oil flow
802 l/min
Max. frequency
23/1380 Hz / RPM
Max. centrifugal force
2555 kN
Max. pulling / pressure force
1200 kN
Vibratory mass without clamp
8200 kg
Total mass without clamp
13300 kg
Max. effective amplitude
29,3 mm
Recommended power station
900
Clamping heads
Agriplex 350 T, Duplex 2 x 150 T.
For sheet piles Agriplex 350 T (Clamp weight)
3100 kg
For pipes and columns Duplex 2 x 150T (Diameter (min. and max.))
650/1676
