Vibratory Hammer PTC 200HDRK

Вибропогружатель
Фотография новости



The vibratory hammer PTC 200HD with constant eccentric moment technology is designed for working with large and heavy sheet piles, as well as casing columns weighing up to 150 tons. This machine features a simple and reliable construction, which ensures long service life without significant maintenance costs.



The PTC 200HD vibratory hammer is well suited for operations in open areas away from other objects. It has a hydraulic power of 709 kW, a maximum vibration frequency of 23 Hz / 1380 rpm, centrifugal force of 4258 kN, and maximum extraction force of 1800 kN.



In its standard configuration, the PTC 200HD vibratory hammer can operate on slopes of up to 15 degrees. For casing pipes and columns, an additional Quadriplex 4×150 t clamping head can be ordered. The vibratory driving process is carried out with reduced noise levels.



The PTC 200HD vibratory hammers can be equipped with a cooling system for continuous operation.



Technical specifications

Centrifugal force (max)
4 258 kN
Eccentric moment
200 m. kg
Hydraulic power
709/964 kW/hp
Number of revolutions (max)
1 380 rpm
Frequency (max)
23 Hz
Pulling force (max)
1 800 kN
Dynamic weight, without clamping device
13 340 kg
Total weight, without clamping device
19 540 kg
Amplitude of oscillations, without clamping device/driving profile
30 mm
Oil flow rate (max)
1 182 l/min

Dimensions

Length L
2 300 mm
Width B
1 520 mm
Width at center
800 mm
Height without clamp H
4 000 mm

Drive unit

Type
PTC 1200C
Engine
diesel 2XCat C18 ACERT
Power, max
806/1 095 kW/hp
Fuel tank capacity
1 980 l
Weight without fuel
12 900 kg
Length L
5 000 mm
Width B
2 190 mm
Height H
2 230 mm

Clamping device

Type
Quadriplex 4×150
Weight
9 500 kg
